Musical Fidelity Nu-Vista 600.2 Integrated Amplifier

Meet the Nu-Vista 600.2 – a powerhouse of sound with top-tier tech and a rock-solid design. With a fully balanced signal path and plenty of inputs, it plays nice with all your gear. Handmade in Europe, it’s a fantastic upgrade option for anyone who takes their tunes seriously.

Specifications

Output

• Power: 160W into 8 ohms, 300W into 4 ohms, 500W peaks into 2 ohms
• Voltage: 36 Volts RMS, 20Hz to 20 kHz; onset of clipping, 147 Volts peak to peak
• Current: 50 Amps peak to peak
• Damping factor: 100
• Output devices: 2 pairs per channel
• Gain: Preamp 4.3x (12.6dB) at maximum volume, Power Amp 34x (31dB)

Line input

• THD+N: < 0.005 % typical, 20Hz to 20 kHz
• SNR: > 107dB ‘A’-weighted
• Input impedance: 100 k Ohms
• Frequency response: + 0, –0.1dB, 10Hz to 30 kHz

Connections

• Line level inputs: 4 pairs line level RCA connectors; 2 pairs line level balanced XLR connectors
• Line level outputs: 1 pair line level RCA connectors, constant level LINE outputs; 1 pair line level RCA connectors, PREAMP outputs for e.g. biamping; 1 pair line level XLR connectors, PREAMP outputs for e.g. biamping
• Speaker outputs: 2 pairs 4mm banana plug/binding posts

Power requirement

• Mains voltages: 115/230VAC 50/60Hz (factory pre-set); 100VAC 50/60Hz (alternative)
• Consumption: <0.5W in standby mode (orange LED lit); 75W on and idle (blue LED lit); 600 Watts maximum

General Information

• Dimensions (WxHxD): 483 x 187 x 510 mm
• Weight: 36 kg net / 44.3 kg boxed
